CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Summary of Specifications
12.6 Miscellaneous
Front panel
Tactile keypad, 6 keys (Up/Down, Left/Right, Enter/Clear)
Vacuum Fluorescent Display (blue) - 2 lines of 24 characters
Loopbacks
Internal IF loopback, RF loopback, digital loopback, and inward/outward loopback
Fault relays
Hardware fault, Rx and Tx Traffic Alarms
M&C Interface
EIA-232 and EIA-485 (addressable multidrop, 2-wire or 4-wire)
Ethernet
10/100 Base Tx for http:, SNMP and Telnet interfaces
M&C Software
CMCS software for control of local and distant units
Dimensions
CDM-570L: 1U high, 16 inches (406 mm) deep
CDM-570: 1U high, 12 inches (304.8 mm) deep
Weight
CDM-570L: 7 lbs (3.2 kgs) max (not including BUC Power Supply)
CDM-570: 5 lbs (32.3 kgs) max
AC consumption CDM-570L (without BUC Power Supply, or IP module):
29 Watts (typical) 32 Watts (maximum)
CDM-570L When fitted with 150 Watt BUC power supply:
250 Watts (maximum)
CDM-570: (without IP module):
29 Watts (typical) 32 Watts (maximum)
Typical measured VA, Power Factor and Power data:
CDM-570L - no IP module installed:
240V 50 Hz: Power Factor = 0.44, 65VA, 29 Watts
110V 60 Hz Power Factor = 0.55, 50VA, 28 Watts
CDM-570L - with IP module installed:
240V 50 Hz Power Factor = 0.46, 80VA, 37 Watts
110V 60 Hz Power Factor = 0.56, 63VA, 35 Watts
CDM-570 - no IP module installed:
240V 50 Hz Power Factor = 0.33, 87VA, 29 Watts
110V 60 Hz Power Factor = 0.53, 51VA, 28 Watts
CDM-570 - with IP module installed:
240V 50 Hz Power Factor = 0.36, 99VA, 37 Watts
110V 60 Hz Power Factor = 0.54, 64VA, 35 Watts
Operating voltage
100 - 240 volts AC, +6%/-10% - autosensing
(total absolute max. range is 90 - 254 volts AC)
Optional -48 volt DC supply available
Operating temperature
0 to 50
o
C (32 to 122
o
F)
12.7 Approvals
“CE” as follows:
EN 55022 Class B (Emissions)
EN 50082-1 (Immunity)
EN 60950 (Safety)
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
EN 61000-4-9
EN 61000-4-11
EN 61000-4-13
FCC
FCC Part 15 Class B
12–7
