CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.5 (ODU,ENABLE) STATUS
STATUS:PS:OK RF:OK UC:OK
LNA:OK AG:OK HP:OK DC:OK
This menu displays summary information. The operator may select 1 of 6 detailed status
windows. Use the ◄ ► keys, then press ENT.
The cursor may be moved over 6 of the 7 status parameters to view more detailed status
information. These screens are continually updated while being viewed.
AG = AGC Status
DC = Down Converter
HP = HPA Status
LNA = Low Noise Amplifier (No further detail)
PS = Power Supplies
RF = Reference
UC = Up Converter
FT = Fault
NA = Not Applicable
OK = OK – No Fault
P/Supplies: 7V:OK 17V:OK
-7V:OK 12V:OK
REF:WARM 72M:OK RANGE:NA
SRC:INT XLK:NA PHASE:NA
UPCONV STATUS: OVRTMP:OK
SSYN:OK KSYN:OK PRG:OK
AGC STATUS: EIP:OK
LOOP:OK IIP:OK
HPA: OVERTMP:OK 9.75V:OK
-5V:OK BIAS:OK PRG:OK
DNCONV STATUS: OVRTMP:OK
LSYN:OK KSYN:OK PRG:OK
F–24
