CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Front Panel Operation MN/CDM570L.IOM
6–19
6.7.10 (CONFIG, TX) INVERSION FUNCTIONS
Select Spectrum or Data, using the ◄ ► arrow keys, then press ENTER.
(CONFIG, TX, INV) SPECTRUM
If Spectrum is selected, the following sub-menu will be displayed:
Select Normal or Inverted, using the ◄ ► arrow keys, then press ENTER.
(CONFIG, TX, INV) DATA
If Data is selected, the following sub-menu will be displayed:
Select Normal or Inverted, using the ◄ ► arrow keys, then press ENTER.
Tx Inversion functions:
Spectrum Data (◄ ►,ENT)
Tx Spectrum: Normal
Inverted (◄ ►,ENTER)
Tx Data Sense: Normal
Inverted (◄ ►,ENTER)
