Comtech EF Data CDM-570L - Figure 7-10. 16-QAM Viterbi, Rate 3;4 and Rate 7;8 with 220,200 RS Outer Code

CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Forward Error Correction Options MN/CDM570L.IOM
1E-9
1E-8
1E-7
1E-6
1E-5
1E-4
1E-3
1E-2
1E-1
1 2 3 4 5 6 7 8 9 10 11 12
Eb/No in dB
Specification limit Rate
3/4 Viterbi and 220,200
RS Outer Code
16-QAM Viterbi, Rate 3/4 and Rate 7/8
with 220,200 RS Outer Code
Uncoded BPSK/QPSK
Uncoded 16-QAM
Specification
limit Rate 7/8
Viterbi and
220,200 RS
Outer Code
Typical
Performance
1 2 3 4 5 6 7 8 9 10 11 12
BER
Figure 7-10. 16-QAM Viterbi, Rate 3/4 and Rate 7/8 with 220,200 RS Outer Code
7–19
