Chapter 15. IP MODULE
ETHERNET INTERFACE
OVERVIEW
15.1 Introduction
The optional IP Module Ethernet Interface can be added to make the CDM-570/570L a
high-performance, low-cost, IP-Centric satellite modem well suited for closed network
Single Channel Per Carrier (SCPC) links. It is ideal for many VSAT applications. A
CDM-570/570L with the IP Module can also be utilized in a ViperSat satellite bandwidth
management system. The following chapters focus on the CDM-570/570L IP Module
capabilities and operation. Refer to the ViperSat Operational Manual, for more specific
information on the CDM-570/570L IP Module operation when deployed in a ViperSat
system.
15.2 Major Assemblies
Assembly Description
PL/10235- IP Module
15.3 IP Module Standard Features
• 10/100BaseT Ethernet Interface
• Powerful network management
• Web Server interface for complete product management
• SNMP with public and private MIB
• Telnet interface for remote product M & C
• Console Port interface for local network management
• Remote software/firmware upgrade via FTP
15–1
