CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
17.2.6 Vipersat Configuration Page
The Vipersat Configuration page is activated from the Main Menu page.
The Vipersat Configuration page contains the following options/fields:
Menu Options/Fields Entry Description
STDMA Mode
T
Automatic Switching
A
Unit Role
R
Expansion Unit
E
Network ID
B
Unit Name
N
Receive Multicast Address
V
Managing IP Address
I
Primary Heart Beat
P
Dynamic Power Control Config
C
Set Home State Parameters
H
Vipersat Summary
D
Only used when CDM-570/570L is used in a Vipersat
system. Refer to Vipersat Operators Manual for more
information.
Save Parameters
S
This option allows a user to save the current configuration to
permanent storage. This configuration will be restored on
each successive power cycle.
Exit
X
This option allows a user to exit the current menu and return
to its parent menu.
17–43
