CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Front Panel Operation MN/CDM570L.IOM
6–54
6.16.5 (INFO) FRAME (Framing and EDMAC information)
Examples:
This screen shows EDMAC mode, and shows if the unit is EDMAC Master or Slave,
with the appropriate address. Pressing ENTER or CLEAR takes the user back to the
previous menu.
6.16.6 (INFO) INTFC (Interface information)
This screen shows details of the electrical interface type of the main data port. If RS422,
V.35 or RS232 is selected, the menu will also indicate the operation of RTS/CTS.
Pressing ENTER or CLEAR takes the user back to the previous menu. For example:
Framing: Disabled
(ENTER or CLEAR)
Framing:AUPC-Only,EDMAC2
(ENTER or CLEAR)
Framing: AUPC+EDMAC
Slave, 0241 (ENT or CLR)
Framing: AUPC+EDMAC2
Master,0240 (ENT or CLR)
Interface:G.703 E1-Unbal
HDB3 (ENTER or CLEAR)
Interface: RS422 (ENT)
RTS/CTS Loop, No Action
Interface: G.703 T1 B8ZS
533-655 feet(ENT or CLR)
Interface: IP (ENT)
IEEE 802.3 Ethernet
