CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
17.2 Main Menu Page
Menu pages are followed by a table listing the Menu Options/Fields, required Entry, and
Descriptions.
The Main Menu page has the following options/fields:
Menu Options/Fields Entry Description
Administration
A
The Administration menu provides a basic set of
standard admin functions to the
IP Module. When
connected via telnet, navigation to this menu will be
restricted to the admin user.
Interface Configuration
I
Allows the user to configure the Ethernet and Satellite
interfaces.
QoS Configuration
Q
Allows the user to define QoS rules for up to 32
different types of flows.
Route Table
R
Allows a user to define how the
IP Module will route
packets that it receives on its Ethernet and Satellite
interfaces.
Protocol Configuration
P
The Protocol Settings option allows the user to
configure various protocols used by the
IP Module.
These protocols currently include ARP and IGMP.
Vipersat Configuration
V
Only used when the CDM-570/570L is used in a
Vipersat system.
17–3
