CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Front Panel Operation MN/CDM570L.IOM
6–48
6.14.5 (MONIT) AUPC
If the user selects AUPC, and the modem is not in Framed mode, the following sub-
menu is displayed:
If the user selects AUPC, and the modem is in Framed mode, the following sub-menu is
displayed:
The top line displays the value of Eb/No of the demodulator at the distant end of the
satellite link. The Eb/No will display Unlock if the remote demod is unlocked. The
bottom line shows how much the AUPC system has increased the output power. If AUPC
is not enabled, the value of Tx Power Increase will show as 0.0 dB.
6.14.6 (MONIT) ODU
If ODU is selected, the following sub-menu is displayed:
Select LNB or BUC, using the
◄ ► arrow keys, then press ENTER.
If LNB is selected, the following menu is displayed:
The menu displays the LNB Voltage and Current. Press ENTER or CLEAR to
return to the next-highest menu.
AUPC:Remote EbNo =14.0dB
TX Power Increase =2.2dB
Outdoor Unit Monitor:
BUC LNB (◄ ►,ENTER)
LNB Voltage: 13.1 volts
LNB Current: 235 mA(ENT)
Framing is required for
AUPC Monitor (ENT or CLR)
