If BUC is selected, the following menu is displayed:
The menu displays the following parameters:
DC
(DC Power) If a BUC supply is installed, displays
measured BUC supply voltage and load current, measured
at the Tx-IF connector.
T
(Temperature) If BUC FSK is enabled, displays BUC
ambient temperature in °C.
SW
If BUC FSK is enabled, displays the M&C software
version of the BUC.
PLL
If BUC FSK is enabled, displays the fault status of the
BUC PLL synthesizers.
Pwr
(Output) If BUC FSK is enabled, displays the output power
as measured by the BUC power monitor.
Press ENTER or CLEAR to return to the next-highest menu.
BUC:DC=47.8V,3.25A SW=05
T=+38C PLL=Flt Pwr=02.1W
