CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.4.24 (ODU,ENABLE, INFO) HPA
HPA: On
Fault Logic: No Summary
This window provides the current configuration of the HPA functions, press ENT.
F.3.4.25 (ODU,ENABLE, INFO) LNA
LNA: On
Fault Logic: No Summary
This window provides the current configuration of the LNA functions, press ENT.
F.3.4.26 (ODU,ENABLE,INFO) EQUIP (Equipment)
EQUIP-TYPE: KST-2000A
HPA-TYPE: CEFD-SSPA
F.3.4.27 (ODU,ENABLE,INFO) ASSEMBLY+SN
ASSEMBLY INFO: M&C
AS:11565-4 SN:001370891
Note: The blinking cursor is on the M&C. Use the ▲ ▼ keys to view additional
assembly and S/N information for the Up Converter, Down Converter, and HPA.
F.3.4.28 ODU,ENABLE,INFO) FW (Firmware)
FIRMWARE INFO: M&C
FW:10303-1D VER:01.01.05
Note: The blinking cursor is on the M&C. Use the ▲ ▼ keys to view additional
firmware information for the Up Converter, Down Converter, and HPA.
F–23
