CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix D MN/CDM570L.IOM
14
For HDLC address [SMALL NETWORK] in hex <0x1 - 0xFE, enter = 0000>:
select 1
15
CDM-IP 2 Route Table should display the following:
Route Name Dest IP/SNet Bits Next Hop MultiCast State
Route001..[test 172.16.10.0/24 0x1 N/A toSat]
Set Remote HDLC IP Address to 192.168.1.2
At this point the basic configuration is over and you should be able to:
Ping PC 1 from PC 2 and vice versa
Ping CDM-IP 2 from PC 1 and vice versa
Pass any other data between the 2 PCs
1
From PC1
Ping 172.16.10.1 (CDM-IP 1)
Ping 172.17.10.2 (CDM-IP 2)
Ping 172.17.10.11 (PC 2)
2
From PC2
Ping 172.17.10.1 (CDM-IP 2)
Ping 172.16.10.1 (CDM-IP 1)
Ping 172.16.10.11 (PC 1)
D–10
