CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Front Panel Operation MN/CDM570L.IOM
6–36
(CONFIG, ODU, BUC) M&C-FSK
If M&C-FSK is selected, the following sub-menu is displayed:
Select Comms, Address, or Tx-On/Off, using the ◄ ► arrow keys, then press
ENTER.
FSK-Comms
If an FSK-capable BUC is employed, this menu turns
the FSK between the modem and BUC either ON or
OFF.
Address
(Address) This menu permits the user to enter the
logical address of the BUC, from 1 to 15.
(CONFIG, ODU, BUC, M&C-FSK) FSK-Comms
If FSK-Comms is selected, the following sub-menu is displayed:
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, BUC, M&C-FSK) Address
If Addr is selected, the following sub-menu is displayed:
Edit the value of the address using the ▲ ▼ arrow keys, then press ENTER. The
valid range is from 01 to 15.
BUC M&C(FSK): FSK-Comms
Address Tx-On/Off (◄ ►)
BUC M&C FSK Comms:
On Off (◄ ►,ENTER)
BUC FSK Address: 01
(▲ ▼,ENTER)
