CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
Menu Options/Fields Entry Description
Tx Encoder Rate
R
1 – 5/16
2 – 21/44
3 – 1/2
4 – 2/3
5 – 3/4
6 – 7/8
7 – 0.95
9 – 1/1
Tx Modulation Type
M
Sets transmit modulation type
1 -- BPSK
2 -- QPSK
3 -- OQPSK
4 – 8-PSK
5 -- 16-QAM
6 -- 16-QAM
Tx Spectrum
U
1 - Normal
2 - Inverted
Tx Data Inversion
I
1 - Normal
2 - Inverted
Scrambler
B
1 - Off
2 – On-Default
3 – On-IESS-315
Tx Output Power
P
Valid ranges are from 0.0 to 40.0 dBm
(minus sign assumed)
Carrier
C
1 - OFF
2 – ON
3 – Rx-Tx Inhibit – Turn off the transmitter if the Rx
is not locked
Save Parameters
S
This option allows a user to save the current
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
Exit
X
This option allows a user to exit the current menu and
return to its parent menu.
17–47
