CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
Menu Options/Fields Entry Description
Frequency Reference
R
1 -- Internal 10 MHz
2 -- External 1 MHz
3 -- External 2 MHz
4 -- External 5 MHz
5 -- External 10 MHz
6 -- External 20 MHz
Test Mode
T
1 -- Normal
2 -- IF_loopback
3 -- Digital_loopback
4 -- I/O_Loopback
5 -- RF Loopback
6 -- Tx_CW
7 -- TX_alt_101010
Save Paramexters
S
This option allows a user to save the current
configuration to permanent storage. This
configuration will be restored on each
successive power cycle.
Exit
X
This option allows a user to exit the current
menu and return to its parent menu.
17–53
