17.2.8.7 Block Up Converter (BUC) Configuration
The Block Up Converter (BUC) Configuration page is activated from the Configuration
page.
The Block Up Converter (BUC) Configuration page contains the following options/fields:
Menu Options/Fields Entry Description
BUC Address
A
1 to 15
BUC RF Output
R
Enabled/Disabled
BUC DC Power
W
Enabled/Disabled
BUC 10 MHz Reference
P
Enabled/Disabled
BUC Current Alarm Upper Limit (mA)
H
500 to 4000
BUC Current Alarm Lower Limit (mA)
C
0 to 3000
BUC LO Frequency (MHz)
F
3000 to 65000, 0 to disable
Save Paramexters
S
This option allows a user to save the current
configuration to permanent storage. This
configuration will be restored on each
successive power cycle.
Exit
X
This option allows a user to exit the current
menu and return to its parent menu.
