CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
Menu Options/Fields Entry Description
Queue01…08 Read
Only
Statistics are displayed in a table format showing:
Pre-Header Comp Bytes
Post-Header Comp Bytes
Header Comp % Savings
Pre-Payload Comp Bytes
Post-Payload Comp Bytes
Payload Compression Ratio
All traffic that does not fall within a defined QoS Rule
will be indicated in the ‘Global’ (Default Rule Queue).
Global Read
Only
CLEAR
C
Allows a reset of the Statistics of a specific Queue.
ClrAll
A
Resets all Compression Statistics.
Allows the user to view up to 8 different Queues per
screen. To allow editing on any of the 32 entries that
can be defined, the user can select a base address to
control which 8 QoS Queues are displayed. For
example, if the user wants to view QoS Queues 16-24,
then a Base value of 16 should be defined.
Base [1]
B
Save Parameters
S
This option allows a user to save the current
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
Exit
X
This option allows a user to exit the current menu and
return to its parent menu.
17–71
