CDM-570/570L Satellite Modem with Optional IP Module Revision 4
SNMP Interface MN/CDM570L.IOM
FW10874-
4D.mib
CDM-570/570L
MIB file
CDM-570/570L MIB file consists of all of the OIDs for management of the
CDM-570/570L modem functions
FW10874-
5A.mib
CDM-570/570L
Traps MIB file
CDM-570/570L Trap MIB file is provided for common SNMPv1 traps
Fw10874-
6A.mib
CDM-570L L-
Band BUC and
LNB MIB
CDM-570L MIB file consists of all of the OIDs for management of the BUC
and LNB functions
FW10874-7-MIB CDM-570L Trap MIB file is provided for BUC and LNB SNMPv1 traps
These MIB files should be compiled in a MIB Browser or SNMP Network Monitoring
System server.
Note: The CDM-570/570L SNMP agent supports both SNMPv1 and v2c. The
CDM-570/570L Traps file only needs to be compiled if SNMPv1 traps are to be used.
IMPORTANT
Any changes made to modem parameters will be lost if the IP Module is reset or
loses power unless the changes are saved to flash. This applies to all of the IP
parameters and Base Modem parameters. The IP and Base Modem parameters
can be saved by a SET of the cdmipSaveConfiguration OID within the
cdmipController MIB.
19–2
