CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.3.8 (ODU,ENABLE,1:1,CSAT#1) Selections
(ODU,ENABLE,1:1,CSAT#2) Selections
(ODU,ENABLE,STAND-ALONE) Selections
ODU SELECT: Config Info
Monitor Alarms (◄ ►,ENT)
The user is prompted from 1 of 4 sub-menu branches using the ◄ ► arrow keys, then
press ENT.
F.3.3.9 (ODU,ENABLE,1:1,CSAT#1) CONFIG (Configuration)
(ODU,ENABLE,1:1,CSAT#2) CONFIG (Configuration)
(ODU,ENABLE,STAND-ALONE) CONFIG (Configuration)
ODU CONFIG: Transmitter
Receiver Misc (◄ ►,ENT)
The user uses this menu item to select either the ‘Transmitter configuration branch”,
“Receiver configuration branch” or “Miscellaneous configuration branch”. Use the
◄ ►
arrow keys, then press ENT.
F.3.3.10 (ODU,ENABLE,1:1,CSAT#1,CONFIG) TRANSMITTER
(ODU,ENABLE,1:1,CSAT#2,CONFIG) TRANSMITTER
(ODU,ENABLE,STAND-ALONE,CONFIG) TRANSMITTER
ODU TX: Frequency Atten
Amplifier Mute Slope ◄ ►
This menu item is used to select which ODU Transmitter parameter is to be modified.
Use the
◄ ► arrow keys, then press ENT.
F–5
