CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.4.10 (ODU,ENABLE, CONFIG) RECEIVER
KST RX: Frequency Atten
LNA (◄ ►,ENT)
This menu item is used to select which ODU Receiver parameter is to be modified. Use
the ◄ ► keys, then press ENT.
F.3.4.11 (ODU,ENABLE, CONFIG,RECEIVER) FREQUENCY
ODU Rx Frequency:
10950.0 MHz (◄ ►,▲ ▼,ENT)
The user is prompted to edit the receive frequency. This is accomplished by selecting the
digit to be edited, using the ◄ ► keys. The value of the digit is then changed using the
▲ ▼ keys. The user may then press ENT.
F.3.4.12 (ODU,ENABLE, CONFIG,RECEIVER) ATTEN (Attenuation)
ODU Rx Attenuation:
15 dB (◄ ►,▲ ▼,ENT)
The user is prompted to edit the receive attenuation. This is accomplished by selecting
the digit to be edited, using the ◄ ► keys. The value of the digit is then changed using
the ▲ ▼ keys. The user then presses ENT.
F.3.4.13 (ODU,ENABLE, CONFIG,RECEIVER) LNA / LNB
If the ODU is a KST-2000A unit, the following menu is displayed.
LNA: State Fault-Logic
Calibrate (◄ ►,ENT)
If the ODU is a KST-2000B unit, a different menu is displayed.
LNB: State Fault-Logic
Calibrate Band (◄ ►,ENT)
The user may select a parameter using the ◄ ► keys, then press ENT.
F–20
