UTXCLOCKA
WTXCLOCKB
PTXDATAA
STXDATAB
VRXCLOCKA
XRXCLOCKB
F
T RXDATAB
YINTTXCLKA
AA INT TX CLK B
B SIGGROUND
DCTS
CRTS
TX CLOCKA 24
TX CLOCKB 11
TX DATA A 2
TX DATA B 14
RX CLOCKA 17
RX CLOCK B 9
RX DATAA 3
INT TX CLKA 15
INT TXCLKB 12
1
A
SIG GROUND 7
25 PIN D TYPE MALE
34 PIN WINCHESTERFEMALE
LENGTH = TBD
TWISTED PAIR
TWISTED PAIR
TWISTED PAIR
TWISTED PAIR
TWISTED PAIR
(7 TWISTED PAIRS PLUS OVERALL FOIL/BRAID
SCREEN BELDEN 8107OR 8307, OR NEAR
EQUIVALENT)
CDM-570LEIA530TOV.35DCECONVERSIONCABLE
25 PIN D MALE
NOTES:
USE METAL BACKSHELLS
FOR D TYPE CONNECTORS
ENSURE SHIELDING FOIL
AND/OR BRAID IS BONDED
TO METAL BACKSHELL FOR
EMC SHIELDING
RCVR READYA 8
RX DATA B 16
R RXDATAA
34 PIN
WINCHESTER
FEMALE
RS A 4
CS A 5
LINK
TOGETHER
IN SHELL
EOSR
SHIELD
RLSD
OVERALL SHIELD
SHIELD
DM A 6
