5. Each Component Function
48 User’s Manual
IPC-BX/M600(PCW)C4P
Top cover
MOUSE
PRINTER
HDD LED
POWER LED
VGA
SERIAL2
SERIAL1 RESETUSB FD
RAS
POWER SW
AC inlet
Keyboard
UTP(Ethernet)
PCMCIA slots 1 and 2
LCD
Expansion slot(PCI/ISA) x 2 and PCI x 2
Side view
IPC-BX/M600(PCW), IPC-BX/M600(PCW)CP
IPC-BX/M600(PCW)C IPC-BX/M600(PCW)C4P
Secondary IDE Connector
Figure 5.1. Component Identification
