5. Each Component Function
User’s Manual
49
Table 5.1. Component Functions
KB Keyboard connector (MINI-DIN, 6pin)
MOUSE PS/2 mouse connector (MINI-DIN, 6pin)
FD Floppy disk drive connector (26pin, half-pitch connector)
SERIAL1 Serial port 1 connector (9pin, male D-SUB)
SERIAL2 Serial port 2 connector (9pin, male D-SUB)
VGA CRT connector (15pin, female HD-SUB)
PCMCIA PCMCIA card slot <C, CP and C4P models>
PRINTER Parallel port connector (25pin, female D-SUB)
RAS RAS function and RS-485 connector (15pin, female D-SUB)
RESET Hard reset push button
USB USB port connector
UTP Ethernet connector
LCD LCD connector (20pin, half-pitch connector) <C, CP and C4P models>
Expansion slots
PCI/ISA expansion board slot x 2 <CP model>
PCI/ISA expansion board slot x 2, PCI expansion board slot x 1 <C4P model>
POWER LED Power ON indicator
HDD LED Internal hard disk access lamp
POWER SW Power switch
AC INLET AC power supply input connector
SECONDARY IDE Secondary IDE connector (dedicated 40pin half-pitch connector)
