5 Maintenance
Operator manual: Postmix tower
Ribbon
46
Cornelius Deutschland GmbH
Document no. TD0000000
Version: 19/10/2017, Index 3
16. Clean the grill with a clean, damp cloth and, if necessary,
an approved cleaning agent.
17. Dry the grill with a paper towel.
18. Clean the drip tray with a clean, damp cloth and, if nec-
essary, an approved cleaning agent.
19. Dry the drip tray with a paper towel.
20. Attach the panel to the unit.
21. If a drain set (accessory) is used, install it as follows; oth-
erwise proceed with step 22, page 47.
a. Slide the O-ring (Figure 75/1) onto the drain fitting
(Figure 75/2), all the way to the top edge.
Figure 72
Figure 73
Figure 74
1
2
Figure 75
