2) Configure parameters. See Table 1-8.
⚫
⚫ Table 1-8
Parameter
Description
Channel
In the Channel list, select the channel that you want use on the
Device to connect the remote device.
Manufacturer
In the Manufacturer list, select the manufacturer of the remote
device.
IP Address
In the IP Address box, enter the IP address of remote device.
The default is 192.168.0.0 which the system cannot connect to.
RTSP Port
The default value setting is 554. You can enter the value according to
your actual situation.
HTTP Port
The default value setting is 80. You can enter the value according to
your actual situation.
If you enter other value, for example, 70, and then you should enter
70 after the IP address when logging in the Device by browser.
User Name
Enter the user name of the remote device.
Password
Enter the password of the user for the remote device.
Remote Channel
Enter the remote channel number of the remote device that you want
to add.
Decoder Buffer
In the Decoder Buffer list, select Default, Realtime, or Fluent.
Protocol Type
⚫ If the remote device is added through private protocol, the default
type is TCP.
⚫ If the remote device is added through Onvif protocol, the system
supports Auto, TCP, UDP, or MULTICAST.
⚫ If the remote device is added through other manufacturers, the
system supports TCP and UDP.
Encrypt
If the remote device is added through Onvif protocol, selecting the
Encrypt check box will provide encryption protection to the data being
transmitted.
To use this function, the HTTPS function should be enabled for the
remote IP camera.
⚫
3) Click OK.
⚫ The remote device information is displayed on the Added Device list. Step 4 Click Next to complete
the remote device registration.
⚫ Click to change the remote device information. Click to delete remote device.
