⚫ Figure
1-95
⚫ This function allows you to clip some footages to a new file and then save it to the USB device. See Figure
1-96. Follow the steps listed below.
⚫ Step 1 Select a record first and then click to playback.
⚫ Step 2 Select a time at the time bar and then click to start clip, Step 3 Select a time at the time bar and
then click to stop clip, Step 4 Click , system pops up dialogue box to save the clip file.
⚫ Figure 1-96
⚫ Clip function is for one-channel/multiple-channel.
⚫ Max save 1024 files at the same time.
⚫ This function is not for the file already checked in the file list.
1.6.2.4 Record Backup
⚫ This function is to backup files you checked in the file list, or the file you just clip.
⚫ Step 1 Select the recorded video file that you want to back up. You can select the following two types of files:
⚫ Recorded video file: Click , the File List area is displayed. Select the file(s) that you want to back up.
⚫ Saves the clip footages as a record file.
⚫ Step 2 Click , the BACKUP interface is displayed. See Figure 1-97.
