Table 3-11 Torque and Conductor Specifications
Connection Point Conductor Range Torque Value
#6-3/0 AWG (CU)
#6-3/0 AWG (AL)
14.25 N-m (126 in-lbs）
（
）
（
）
The AC Terminals are 90C rated. The maximum acceptable conductor
size that may be terminated to the AC output terminal is restricted based
on the compression lug maximum dimensions shown in Figure 3-29.
Figure 3-28 Compression Lug (OT Terminal) maximum dimensions
