Creality CR-10 SE User Manual

3. Assembly Procedure
04
3.2 Gantry Frame Assembly Installation
Place the gantry frame assembly in the base slot and lock it using four M5x45 screws aligned with the holes from the bottom.
Bottom view

Creality CR-10 SE Specifications

General

Build Volume	300 x 300 x 400 mm
Nozzle Diameter	0.4 mm
Bed Temperature	up to 110°C
Supported Filaments	PLA, ABS, PETG, TPU
Extruder Type	Direct Drive
Filament Diameter	1.75 mm
Display	4.3-inch touch screen
Printing Speed	up to 200 mm/s
Nozzle Temperature	Up to 300°C
Connectivity	USB
Power Supply	350W
Leveling	Automatic Leveling
