Web Interface Configuration Guide — Doc. 8907B HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E • 27
1.
Click the Edit button ( ) in the Actions column to edit the AUX settings of the
selected AUX output.
2. In the Edit Output dialog enter the following:
a. Optionally, edit the name of the AUX output in the Name field.
b. Move the AUX Volume slider to the right to increase or to the left to decrease the
AUX volume or by manually entering a value in the AUXVolume field. Valid value
ranges from -80 dB to 20 dB, adjustable in 1dB increments.
c. Move the AUX Mute slider to right or left to mute or unmute the AUX.
d. Move the AUX Stereo slider to right or left to specify stereo or mono output.
3. Click OK to save. Click Cancel to cancel the changes.
Edit HDMI Output Settings
Click the Edit button ( ) in the Actions column to edit the HDMI settings of the selected
HDMI output. The Edit Output dialog box appears.
