5 INSTRUMENT FEATURES
5.1 Front Exterior Enclosure
NUMBER FEATURE FUNCTION
Display
1/4 VGA full colour resistive touch LCD display,
indicates controller operation
Power LED Indicates unit power status
Status 1, 2, 3 LEDs
Indicates channel status - OK, Low / Mid / High
alarm
Fault LED Indicates unit fault condition
Key Lock (Option -DL) Allows enclosure to be locked
Door Screws Secures the door of the enclosure
Door Mounted Alarm
Audible buzzer that sounds when a channel has
gone into alarm
