Follow the directions until the process is complete. When you exit the screen calibration, the
system will go through a 10 second countdown and then display the home screen.
8 BASIC SETTINGS AND CONFIGURATIONS
8.1 Factory Default Settings
The channel/gas operation type settings are congured at the factory according to the
specications at time of order. The remaining settings are usually congured in the factory
according the default settings listed below. (There may be some differences in the default
settings depending on application.) If changes to the default settings are desired, the settings
can be changed in the eld as indicated in the table below.
ITEM DEFAULT SETTING FIELD CONFIGURABLE SETTINGS
Door Mounted Buzzer
Alarm Level
Silence Interval
Enabled - Normal
High
300 seconds (5
minutes)
Enable, Disable - Normal, Failsafe
Low, Mid, High
0 to 9999 seconds
Strobe
ON Delay
Silence Interval
Enabled - Normal
10 seconds
300 seconds (5
minutes)
Enable, Disable - Failsafe, Normal
value is application dependant
0 to 9999 seconds
Data Logger
Enabled
5 minutes
Enable, Disable
1 to 1080 (18 hrs)
Relay 1
Relay 2
Relay 3
ON Delay (each relay)
OFF Delay (each relay)
Low - Failsafe
Mid - Failsafe
High - Failsafe
10 seconds
10 seconds
Low, Mid, High - Failsafe, Normal
Low, Mid, High - Failsafe, Normal
Low, Mid, HIgh - Failsafe, Normal
value is application dependant
value is application dependant
Alarm Setpoints
values are gas
dependant
Ascending
values are gas dependant
Ascending, Descending (ie. O
2
)
LAN Modbus®
Baud Rate 19,200 changing is not recommended
