9.3 Enclosure Door Lock and Keys (Option -DL)
The optional door lock is factory installed at the time of order. Together with the password
protected menus, the lock prevents unauthorized access and eliminates tampering within the
system. Comes with two keys.
9.4 Metal Protective Guard (p/n: SCS-8000-SPG)
The metal protective guard is made of heavy duty metal and helps to protect against
abrasive damage, theft or vandalism to the controller. It is made from 16-gauge galvanized
steel and has 13 mm (½”) square openings in the front to allow gas and air to ow through
to the sensor. With only four slotted mounting holes, installation and removal for equipment
servicing is easy.
Enclosure 16 gauge galvanized steel
Weight 1.7 kg / 3.8 lbs
Size 254 mm W x 241 mm H x 121 mm D / 10.0” in W x 9.5 in H x 4.8 in D
