Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A6780-31500 Case Assy,Diff 1
2 CY-198421-31510 Gear,Diff.Side 1
3 CY-1A6780-31520 Gear, Diff.Side(Lock 1
4 CY-198421-31530 Case,Differential 1
5 CY-198421-31550 Liner,Diff.Side Gear 2
6 CY-194300-31560 Gear, Differential 2
7 CY-194300-31570 Shaft, Differential 1
8 CY-194300-31620 Washer, Differential 2
9 CY-22351-040040 Spring Pin 4X40 1
10 CY-24101-060064 Ball Bearing 1
11 CY-24101-060074 Ball Bearing 1
12 CY-26156-100162 Bolt M10X16 6
110
FIG. 55. DIFFERENTIAL GEAR
