Sx3100

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-1A7540-32610 Housing, Rear Axle L 1

2 CY-1A7540-32620 Housing, Rear Axle R 1

3 CY-198165-32630 Packing,Housing 1

4 CY-1A6680-32630 Gasket 2

5 CY-1A7540-32640 Cover, Rear Axle 2

6 CY-198421-32660 Stopper,Steel Plate 4

7 CY-198290-32750 Seal Tc253506,Oil 2

8 CY-22217-100000 Spring Washer 10 1

9 CY-22287-080000 Locking Washer 1

10 CY-22312-080180 Parallel Pin, M8X16 2

11 CY-22312-080200 Parallel Pin, M8X20 4

12 CY-22312-080320 Parallel Pin, M8X32 2

13 CY-23491-140002 Plug 14 2

14 CY-24311-000160 O-Ring 1A P-16.0 2

15 CY-26013-080202 Bolt W/Washer M8X20 4

16 CY-26013-080502 Bolt M 8X 50 1

17 CY-26013-100402 Bolt M10X 40 6

18 CY-26013-100452 Bolt M10X 45 16

19 CY-26013-100502 Bolt M10X 50 4

20 CY-26013-100502 Bolt M10X 50 6

21 CY-26013-100552 Bolt M10X 55 2

22 CY-26013-100652 Bolt 10X65 W/Sp.Wshr 1

23 CY-26716-080002 Nut M 8 1

24 CY-26716-100002 Nut 10 1

113

FIG. 57. REAR HOUSING
