Cub Cadet Yanmar Sx3100 - Page 119

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8300-34800 Tire Kit, Rear L R4 1
2 CY-1A8300-14840 Valve, 1
3 CY-1A8300-34820 Tire, 14X17.5 R4 1
4 CY-1A8300-34830 Wheel, 1
5 CY-1A8300-34810 Tire Kit, Rear R R4 1
6 CY-1A8300-14840 Valve, 1
7 CY-1A8300-34820 Tire, 14X17.5 R4 1
8 CY-1A8300-34830 Wheel, 1
119
FIG. 63. REAR TIRE R4
