Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8160-35080 Head,Pedal 2
2 CY-1A8300-35100 Pedal Kit, Hst 1
3 CY-194630-27190 Linner 17.5X27X1.6 5
4 CY-1A8300-35110 Pedal Assy, Forward 1
5 CY-1A8300-35200 Pedal Assy, Reverse 1
6 CY-1A8300-35270 Seal, G172303 2
7 CY-24550-017150 Bush 17X15 2
8 CY-1A8300-35240 Bracket, Hst Pedal 1
9 CY-1A8300-35320 Shaft Assy, Pedal 1
10 CY-1A8300-35360 Shaft Assy, 1
11 CY-198167-35411 Spring,Reverse Pedal 1
12 CY-1A8300-35410 Arm Assy, Shaft 1
13 CY-1A8300-35460 Plate, Link 1
14 CY-1C6900-63890 Spacer 10X15X1 2
15 CY-22137-120000 Washer 12,Polished 2
16 CY-22242-000120 Circlip 12 1
17 CY-22242-000170 Circlip 17 2
18 CY-22272-000150 Circlip E-15 1
19 CY-22351-035036 Spring Pin 3.5X36 2
20 CY-22351-060036 Spring Pin 6X36 2
21 CY-22417-160160 Cotter Pin 1.6X16 2
22 CY-24104-060034 Ball Bearing 4
23 CY-24104-062014 Ball Bearing 6201Uu 1
24 CY-24761-040000 Nipple B,Grease 1
25 CY-1A8300-35170 Head Assy, Pedal 1
26 CY-1A7530-35450 Rod, Hydraulic 1
27 CY-1C6281-52320 Pin 8,Come-Off Snap 1
28 CY-22417-200200 Cotter Pin 2.0X20 1
29 CY-22487-080180 Pin, H8X18 2
30 CY-26013-080252 Bolt M 8X 25 3
31 CY-26106-080352 Bolt M 8X 35 Plated 1
32 CY-26716-080002 Nut M 8 1
123
FIG. 65. HYDRAULIC PEDAL
