Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194740-00322 Turnbuckle 2
2 CY-1C6140-14050 Spacer 25.2X34X2 1
3 CY-194990-20170 Nut W/Washer 8 2
4 CY-1A6781-37300 Pedal L Cmp, Brake 1
5 CY-198165-37340 Conector,Brake 1
6 CY-198167-37350 Collar 34*85 1
7 CY-1A7530-37400 Pedal Assy, Brake R 1
8 CY-198421-37511 Spring,Return 2
9 CY-1A7530-37550 Shaft, Brake Pedal 1
10 CY-194300-37570 Spring, Conical 2
11 CY-198165-37760 Rod R,Brake 2
12 CY-198165-37770 Rod L,Brake 2
13 CY-194080-37781 Pin 8X25 3
14 CY-1C6281-52320 Pin 8,Come-Off Snap 4
15 CY-22272-000190 Circlip E-19 1
16 CY-22487-080400 Pin, H8X40 1
17 CY-22512-070400 Key, 7X40 1
18 CY-24761-040000 Nipple B,Grease 1
19 CY-26716-080002 Nut M 8 2
20 CY-26716-080002 Nut M 8 2
127
FIG. 68. BRAKE PEDAL
