Sx Series

Sx3100

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-1C6140-14050 Spacer 25.2X34X2 1

2 CY-1C6053-32020 Washer 8.5X20X3.2 2

3 CY-1A6781-37500 Arm Cmp, Parking 1

4 CY-1A6781-37530 Arm Assy, Cruse 1

5 CY-1A6781-37590 Arm 1

6 CY-1A7530-37590 Rachet Kit,Park Lock 1

7 CY-1A7530-37600 Rachet Cmp,Park Lock 1

8 CY-1A7530-37710 Bolt, M8 1

9 CY-1A6781-37600 Shaft Cmp, Cruise 1

10 CY-1A6640-37640 Bolt M8 2

11 CY-1A6781-37660 Spring, Return 1

12 CY-1A6781-37710 Spring 1

13 CY-1A7530-37742 Rod,Brake Cmp 1

14 CY-1A7530-37781 Rod,Brake Cmp 1

15 CY-1A6781-37800 Link Cmp, Cruise 1

16 CY-1A6781-37810 Link, Cruise 1

17 CY-1A7530-37830 Cruise Link B 1

18 CY-198165-37840 Spring,P.Brake 1

19 CY-1C6281-52320 Pin 8,Come-Off Snap 4

20 CY-198162-61661 Lever,P.Brake 1

21 CY-198162-61670 Pin 1

22 CY-22137-080000 Washer 8, Polished 6

23 CY-22137-100000 Washer 10,Polished 4

24 CY-22137-120000 Washer 12,Polished 1

25 CY-22272-000190 Circlip E-19 1

26 CY-22417-200320 Cotter Pin 2.0X32 1

27 CY-22417-250250 Cotter Pin 2.5X25 3

28 CY-22512-070200 Key, 7X20 1

29 CY-26051-080002 Nut M 8 2

129

FIG. 69. PARKING BRAKE
