Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A6780-42010 Rock Shaft Assy 1
2 CY-198165-42100 Case,Hydraulic Cyl. 1
3 CY-198165-42400 Plug M 10 1
4 CY-1A6780-44110 Crank Cmp 1
5 CY-22351-060040 Spring Pin 6X40 1
6 CY-198165-44170 Plug M 8X 16 1
7 CY-198165-44180 Piston Rod Comp 1
8 CY-1A6780-44200 Piston Cmp 1
9 CY-1A6780-44240 Cylinder Cmp 1
10 CY-198165-44410 Arm,Cmp Lift 2
11 CY-22242-000340 Circlip 34 2
12 CY-198165-44450 Seal,354507 Oil 2
13 CY-1A6780-44460 Shaft 1
14 CY-198165-45101 Valve Assy, Control 1
15 CY-198165-45010 Valve Kit 1
16 CY-198165-45020 Plate Kit 1
17 CY-198165-45030 Plug Kit 1
18 CY-198165-45140 Spring,Pilot 1
19 CY-198165-45191 Valve Assy 1
20 CY-198165-45270 Spring 1
21 CY-198165-45290 Spacer 3
22 CY-198165-45370 Bolt M 6X 18 3
23 CY-198165-45400 Lever,Cmp Slowreturn 1
24 CY-198165-45500 Cover Kit 1
25 CY-198165-45600 Valve Kit 1
26 CY-198165-45800 Valve,Assy Relief 1
27 CY-198165-47020 Lever Kit 1
28 CY-198165-47030 Shaft Kit 1
29 CY-198165-47520 Circlip 6 1
30 CY-198165-47040 Arm Kit 1
31 CY-198165-47520 Circlip 6 2
32 CY-1A6780-47050 Kit, Pin A 1
33 CY-198165-47530 Circlip 7 1
34 CY-198165-47060 Pin B Kit 1
35 CY-198165-47530 Circlip 7 1
36 CY-198165-47100 Lever,Assy Hydraulic 1
37 CY-198165-47300 Control,Assy Hyd. 1
38 CY-198165-47440 Lever, B 1
39 CY-198165-42120 Packing,Cylinder 1
40 CY-194205-42280 Pipe, Air Breather 1
41 CY-22217-100000 Spring Washer 10 5
42 CY-26013-100252 Bolt M10X 30 4
43 CY-26116-101202 Bolt M10X120 Plated 1
44 CY-26716-100002 Nut 10 4
131
FIG. 70. HYDRAULIC LIFT
