Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194130-01390 Nut M6 1 38 CY-1A6780-46910 Shaft, Link Cam 1
2 CY-194990-20170 Nut W/Washer 8 1 39 CY-198165-46961 Rod B, Link 1
3 CY-1C6053-32020 Washer 8.5X20X3.2 1 40 CY-198165-46980 Rod-End 1
4 CY-192157-33780 Nut 1 41 CY-198165-46991 Link, C 1
5 CY-198165-46110 S.C.V, Cmp 1 42 CY-198165-48550 Plate, Aux 1
6 CY-198165-46130 Valve 2 43 CY-198165-48560 Plug, 9/16 3
7 CY-198165-46140 Spring 2 44 CY-1A8300-48600 Pipe Kit, Scv 1
8 CY-198165-46150 Plug 2 45 CY-198223-46250 Hyd.Quick Coupler 4
9 CY-1A6780-46160 Bolt M 6X 25 1 46 CY-1A7530-48610 Pipe, Scv 1 1
10 CY-1A6780-46170 Bolt M 6X 55 2 47 CY-1A7530-48620 Pipe, Scv 2 1
11 CY-198165-46200 Cover 1 48 CY-1A7530-48630 Pipe, Scv 3 1
12 CY-198165-46210 Gasket 1 49 CY-1A7530-48640 Pipe, Scv 4 1
13
CY-198165-46220 Joint 1 50 CY-1A7530-48760 Mount, Coupler 1
14 CY-198165-46240 Cover, Dust Seal 1 51 CY-194850-49290 Packing 6-1 4
15 CY-198165-46370 Detent 1 52 CY-22242-000220 Circlip 22 4
16 CY-172510-74410 Seal, Dust 2 53 CY-194850-49290 Packing 6-1 3
17 CY-22287-060000 Washer 6 3 54 CY-1C6281-52310 Pin 6,Come-Off Snap 2
18 CY-24311-000140 O-Ring 1A P-14.0 6 55 CY-26716-060002 Nut 6 1
19 CY-24321-000500 O-Ring 1A G-50.0 1 56 CY-26716-080002 Nut M 8 1
20 CY-26016-060102 Bolt M6X 10 3 57 CY-194990-85561 Knob 1
21 CY-198220-46200 Spring 1 58 CY-22117-080000 Washer 8 1
22 CY-1A6780-46260 Bolt 8X65 2 59 CY-22137-060000 Washer 6, Polished 2
23 CY-198165-46470 Rod End 6 1 60 CY-22137-100000 Washer 10,Polished 2
24 CY-198165-46480 Rod End 8 1 61 CY-22157-060000 Washer 6 1
25 CY-1A7500-46491 Holder Assy, Lever 1 62 CY-22242-000100 Circlip 10 1
26 CY-24550-012100 Bush 12X10 2 63 CY-22372-060000 Snap Pin 6 1
27 CY-1A7530-46601 Lever Kit, Scv 1 64 CY-22417-200160 Cotter Pin 2.0X16 1
28 CY-1A6780-46650 Lever B Assy 1 65 CY-22417-250250 Cotter Pin 2.5X25 3
29 CY-1A7530-46651 1A7530-46651 1 66 CY-23414-160021 Gasket 16 8
30 CY-1A7500-46750 Pin Cmp, Stopper 1 67 CY-23857-100000 Joint Bolt 10 4
31 CY-198165-46780 Pin,Lever B 1 68 CY-24321-000550 O-Ring 1A G-55.0 1
32 CY-1A7500-46800 Cam Assy, Link L 1 69 CY-26013-060162 Bolt M 6X 16 1
33 CY-24550-010150 Bush 10X15 2 70 CY-26013-080202 Bolt W/Washer M8X20 2
34 CY-1A7500-46860 Pin, Scv Rock 1 71 CY-26018-060162 Bolt M6X16 3
35 CY-198165-46880 Rod-End, 6 1 72 CY-26116-080354 Bolt M 8X 35 Plated 1
36 CY-1A7500-46900 Cam Assy, Link B 1 73 CY-26346-080002 U-Nut, M8 1
37 CY-24550-010150 Bush 10X15 2 74 CY-26347-060002 U-Nut M 6 4
135
FIG. 73. SUB CONTROL VALVE

Cub Cadet Yanmar Sx3100 Specifications

General

Brand	Cub Cadet
Model	Yanmar Sx3100
Category	Tractor
Language	English
