Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22050 Nut W/Washer 8 4
2 CY-195616-24930 Trim 2
3 CY-1A8300-51110 Harness, Wire A 1
4 CY-1A7130-51130 Diode, 1.5A 4
5 CY-1A7500-51140 Diode 1.5Ax2 1
6 CY-198535-52120 Fuse 10A 4
7 CY-198535-52130 Fuse 15A 3
8 CY-1A7450-52180 Fuse, 25A 2
9 CY-1A7531-52420 Cover, Fuse Box 1
10 CY-1A7500-51160 Clip, Harness 19
11 CY-1A7531-51150 Harness, Wire P 1
12 CY-1A7500-51160 Clip, Harness 4
13 CY-198165-51160 Blow 79A,Slow Cmp 2
14 CY-1A7531-51400 Stay Cmp, Fuse Box 1
15 CY-1A6780-51410 Cable, Battery 1
16 CY-1A7500-51420 Cable, Battery Earth 1
17 CY-194250-51660 Band 250 3
18 CY-194680-51670 Band 1
19 CY-1A7500-51810 Seal,Wiring Harness 1
20 CY-1A7000-61490 Trim, 120 2
21 CY-1E6102-84970 Band 140,Wire Lock 3
22 CY-26018-060202 Bolt M 6X 20 2
23 CY-26106-080122 Bolt M 8X 12 Plated 2
139
FIG. 76. WIRE HARNESS
