Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194850-49290 Packing 6-1 2
2 CY-198165-50110 Switch,Neutral 2
3 CY-198165-52100 Switch,Cmp Lighting 1
4 CY-198165-52110 Knob 1
5 CY-198162-52110 Switch, Starting 1
6 CY-198162-52150 Key Assy 1
7 CY-1A7510-52110 Nut,Switch 2-M4 1
8 CY-198165-52120 Seal 1
9 CY-1A7510-52120 Washer,Switch 1
10 CY-1A7335-52150 Stop Lamp Sw,Delta 1
11 CY-198167-52180 Switch, P. Brake 1
12 CY-1A7500-56610 Gauge, Fuel Oil 1
13 CY-1A7880-57100 Dc Power Outlet 1
14 CY-1A7500-79720 Washer 1
15 CY-1E6460-84220 Nut 2-M3,Switch 1
16 CY-22287-040000 Washer, 4 5
17 CY-26023-030202 Screw, M3X20 2
18 CY-26117-040162 Screw 2
19 CY-26716-040002 Nut M 4 5
143
FIG. 78. SWITCH 1
