REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22140 Nut W/Washer 8 4
2 CY-1A7510-27450 Guide, Change Lever 1
3 CY-194300-37570 Spring, Conical 1
4 CY-1A7510-47711 Guide, Hyd.Lever 1
5 CY-198165-47750 Knob, Hyd.Control 1
6 CY-1A7510-47760 Stopper, Hyd.Control 1
7 CY-1A7510-62100 Bar, Assist 2
8 CY-1A8300-62110 Fender L Cmp 1
9
CY-1A8300-62120
Fender R Cmp 1
10 CY-1A7510621301 Fender Ext L Cmp 1
11 CY-1A7510621401 Fender Ext R Cmp 1
12 CY-1A6640-62960 Grommet 4
13 CY-1A6640-62970 Collar 8.8X12X10 4
14 CY-198165-63130 Screw, Fender Cover 6
15 CY-22157-080000 Washer 8 1
16 CY-22417-200160 Cotter Pin 2.0X16 1
17 CY-26013-080252 Bolt M 8X 25 2
18 CY-26018-060162 Bolt M6X16 8
19 CY-26018-080252 Bolt M8X 25 4
153
FIG. 85. FENDER
