Cub Cadet Yanmar Sx3100 - Page 157

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22050 Nut W/Washer 8 10
2 CY-1C6720-47780 Collar 10X16X15 2
3 CY-1A8300-63140 Rubber, Cushion 2
4 CY-198220-63150 Adjuster, Belt 1
5 CY-1A7500-63171 Seatbelt 1
6 CY-1A7130-63190 Hook R 1
7 CY-1A7530-63200 Bracket Cmp, Seat 1
8 CY-1A7530-63400 Slider Cno 1
9 CY-198220-63450 Holder 2
10 CY-194205-63550 Breather, Air 1
11 CY-1A7130-63600 Hook L 1
12 CY-1A6770-63850 Adjuster, Seat R 1
13 CY-22137-100000 Washer 10,Polished 2
14 CY-22157-100000 Washer 10 2
15 CY-22217-100000 Spring Washer 10 2
16 CY-23065-090450 Hose,9X450 1
17 CY-23080-012000 Clamp 12 2
18 CY-26013-100202 Bolt W/Washer M10X20 4
19 CY-26013-100352 Bolt M10X 35 2
20 CY-26018-080162 Bolt M 8X 16 1
21 CY-26716-100002 Nut 10 2
22 CY-26106-080162 Bolt M 8X 16 Plated 2
23 CY-26716-080002 Nut M 8 2
157
FIG. 87. SEAT BRACKET
