Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1C6281-52320 Pin 8,Come-Off Snap 2
2 CY-1A8300-63000 Seat Assy 1
3 CY-1A8300-63010 Seat Assy, Operator 1
4 CY-1A8300-63500 Bracket Assy, R.H. 1
5 CY-1A8300-63550 Bracket Assy, L.H 1
6 CY-1A8300-63600 Replace Kit, Armrest 1
7 CY-1A8300-63620 Armrest 2
8 N/A Spacer - Order Ref No. 6 2
9
N/A Screw, 5/16-18 Unc - Order Ref No. 6
2
10 N/A Stop Assy, Armrest - Order Ref No. 6 2
11
N/A Stop, Armrest - Order Ref No. 6
2
12
N/A Knob, Adjust - Order Ref No. 6
2
13 N/A Ring, Retainer - Order Ref No. 6 2
14 N/A
Screw, 5/16-18 - Order Ref No. 6
6
15
N/A Spacer - Order Ref No. 6
4
16 CY-1A8300-63100 Hinge Assy, Seat 1
17 CY-1A8300-63200 Pin, Seat 1
18 CY-26106-080162 Bolt M 8X 16 Plated 2
159
FIG. 88. DRIVER SEAT
