Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129008-21000 Crankshaft Assy 1
2 CY-129100-01580 Parallel Pin 8X16 1
4 CY-119803-21200 Gear, Crankshaft 1
5 CY-22512-070140 Key 7X 14 1
7 CY-22351-030010 Spring Pin 3X10 1
8 CY-129004-21650 V-Pulley, Crankshaft 1
9 CY-129795-21661 Washer 1
10 CY-121850-21680 Bolt, V-Pulley 1
11 CY-121111-21501 Bolt, Flywheel 6
12 CY-129232-21590 Flywheel Assy 1
14 CY-119865-21600 Gear, Ring 1
15 CY-119626-21700 Bearing #6901 1
16 CY-129005-22080 Piston Assy 3
18 CY-129005-22500 Ring Set, Piston 3
22 CY-129202-22300 Pin, Piston(D26,L70) 3
23 CY-22252-000260 Circlip 26 6
24 CY-729402-23100 Rod Assy, Connecting 3
27 CY-121550-23200 Bolt, Connecting Rod 6
28 CY-129150-23601 Metal, Crankpin 3
30 CY-129100-23910 Bush, Piston Pin 3
31 CY-129150-23611 Metal.Pin Us=0.25 3
33 CY-129005-22900 Piston W/Ring Os=.25 3
35 CY-129005-22950 Ring Set O.S=0.25 3
17
FIG. 8. CRANKSHAFT & PISTON
