Cub Cadet Yanmar Sx3100 User Manual

Sx Series
Sx3100
Copyright 2010 Cub Cadet Yanmar LLC
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1TN325-41110 HP Pipe A2 1
2 CY-1TN325-41120 HP Pipe B2 1
3 CY-1TN325-41130 HP Pipe A1 1
4 CY-1TN325-41140 HP Pipe B1 1
5 CY-1TN325-41310 HP Hose, Intake 4
6 CY-1TN325-41410 HP Hose A 5
7 CY-1TN325-41430 HP Hose B 2
8 CY-1TN325-41450 HP Hose C 1
9 CY-1TN325-41550 Cover, Clamp 3
10 CY-1TN325-41560 Clamp, Pipe 3
11 CY-1TN325-41750 Dust Plug, Red M 1
12 CY-1TN325-41760 Dust Plug, Blue M 1
13 CY-1TN325-41770 Dust Plug, Yellow M 1
14 CY-1TN325-41780 Dust Plug, Green M 1
15 CY-1TN325-41790 Cover, Hose Intake 1
16 CY-1TN325-41970 Orfice Assy, 1/8 1
17 CY-194850-49290 Packing 6-1 1
18 CY-29622-250001 Band 4
19 CY-1TN325-41510 Cover, Pipe 1
20 CY-1TN325-41730 Clamp, Hose 1
21 CY-1TN325-41910 Coupler,Quick 1/4M 4
22 CY-26106-060302 Bolt M 6X 30 Plated 3
23 CY-26106-080162 Bolt M 8X 16 Plated 2
24 CY-26366-080002 Nut M 8 2
187
FIG. 8. HYDRAULIC PIPING
