Sx Series

Sx3100

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-129001-32001 Pump Assy, Lub. Oil 1

14 CY-129150-32020 Gasket, L.O. Pump 1

15 CY-26450-060252 Bolt M 6X 25 4

16 CY-129232-34800 Dipstick, Lub.Oil 1

17 CY-129468-34810 Guide, Dipstick 1

18 CY-129232-35090 Pipe Assy, Inlet 1

19 CY-24311-000160 O-Ring 1A P-16.0 1

20 CY-26106-060122 Bolt M 6X 12 Plated 1

21 CY-26106-080122 Bolt M 8X 12 Plated 1

22 CY-119802-35100 Bracket Assy, Filter 1

23 CY-119802-35110 Bracket, Filter 1

24 CY-129100-35140 Stud 1

25 CY-129150-35111 Gasket, (Non-Asb.) 1

26 CY-129150-35153 Filter 80X80L 1

27 CY-26106-080202 Bolt M 8X 20 Plated 3

28 CY-114250-39450 Switch,(0.5Kg)L.O. 1

29 CY-124160-39140 Bolt 10, Pipe Joint 1

30 CY-119802-39450 Pipe Assy, Lub. Oil 1

31 CY-129005-59830 Bolt Assy, Joint 1

32 CY-22190-080002 Seal Washer 8S 1

33 CY-23857-030000 Joint Bolt 3 1

34 CY-22190-080002 Seal Washer 8S 1

35 CY-22190-100002 Seal Washer 10S 2

36 CY-26366-060002 Nut M 6 1

FIG. 10. LUBRICATION OIL SYSTEM
