REF
NO.
PART NUMBER DESCRIPTION QTY
2 CY-129232-42000 Pump Assy, Water 1
3 CY-129100-42051 Gasket, (Non-Asb.) 1
4 CY-129100-42121 Plate 1
9 CY-129555-44750 Stud 2
10 CY-119802-49113 Joint 2
11 CY-129916-49740 Plug, Drain R03 2
12 CY-23875-020000 Plug Pt1/4,Steel 1
13 CY-23876-010000 Plug Pt1/8,Screw 1
14 CY-26577-060162 Screw M 6X 16 3
15 CY-129486-42021 Gasket 1
16 CY-129004-42040 Joint 1
17 CY-129486-42140 O-Ring,Cw-P 1
18 CY-124395-49840 Gasket, Thermo. Case 1
19 CY-23414-080000 Gasket 8, Round 1
20 CY-26106-080122 Bolt M 8X 12 Plated 1
21 CY-26106-080162 Bolt M 8X 16 Plated 3
22 CY-26106-080452 Bolt M 8X 45 Plated 1
23 CY-26106-080602 Bolt M 8X 60 Plated 3
24 CY-129120-42350 V-Pulley, F.W.Pump 1
26 CY-25152-003700 V-Belt A37.5 1
27 CY-129655-44740 Fan, Cooling 1
28 CY-121267-44760 Spacer 1
29 CY-26106-060302 Bolt M 6X 30 Plated 4
30 CY-129155-49801 Thermostat,71 1
31 CY-129150-49811 Gasket, (Non-Asb.) 1
32 CY-129350-49530 Cover, Thermostat 1
33 CY-129795-49551 Gasket, (Non-Asb.) 1
34 CY-26306-080002 Nut 2
35 CY-171056-49120 Plug, Drain 1
36 CY-121450-42450 Plug M16 1
37 CY-121250-44901 Switch, Thermo(110 1
38 CY-124465-44950 Gasket 16 1
39 CY-124465-44950 Gasket 16 1
40 CY-129004-49610 Pipe Assy, A Mp2 1
41 CY-129004-49711 Pipe Assy, A Mp2 1
42 CY-119802-49730 Clamp,Cw-T 1
43 CY-124722-59050 Clamp 9 2
44 CY-129004-49620 Pipe Assy, B Mp2 1
45 CY-129004-49721 Pipe, Water B Mp2 1
46 CY-124722-59050 Clamp 9 2
23
FIG. 11. COOLING WATER SYSTEM
