Sx Series

Sx3100

REF

NO.

PART NUMBER DESCRIPTION QTY

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-729232-51320 Injecton Pump Assy 1 96 CY-22190-180002 Seal Washer 18 1

7 CY-119802-51090 Key,Woodruff 4X16 1 97 CY-23887-120002 Plug M12,Hex. 1

32 CY-158600-51270 Stopper 1 99 CY-158553-51770 Bolt 4

33 CY-158563-51281 O-Ring 1 100 CY-158552-52310 O-Ring 1

34 CY-158563-51281 O-Ring 1 101 CY-158552-52400 O-Ring 4E S42 1

34A CY-129008-51390 Setting, Delivery 3 102 CY-22190-120002 Seal Washer 12 2

43 CY-158563-51330 Spring 3 103 CY-22190-180002 Seal Washer 18 2

51 CY-158601-51550 Plug 1 104 CY-22217-140000 Spring Washer 14 1

52 CY-119802-51560 Barrel Plug 1 105 CY-22312-050140 Parallel Pin 5X14 2

53 CY-158552-51570 Pk(Barrel Plug 3 106 CY-22351-050010 Spring Pin 5X10 2

54 CY-158552-51570 Pk(Barrel Plug 1 108 CY-24311-000070 O-Ring 1A P-7.0 1

55 CY-158557-51570 Plug 1 109 CY-24356-010180 O-Ring 1

56 CY-158601-51570 Plug,Water Pump 1 110 CY-24356-010200 Packing, 1020 1

57 CY-158552-51580 Lifter 1 111 CY-26106-060102 Bolt 6X 10 Plated 1

58 CY-119802-51590 Timer Set 1 115 CY-26450-080452 Bolt M 8X 45 4

59 CY-119802-51590 Timer Cmp 1 116 CY-26776-140002 Lock Nut M14 Plated 1

62 CY-158553-51670 O-Ring, 1011 1 119 CY-158553-51551 Joint, Cooling Water 1

63 CY-119802-51680 Backup Ring 1 120 CY-158601-51650 Joint 1

64 CY-119802-51690 O Ring 1 121 CY-158552-51670 Joint 1

65 CY-24356-010200 Packing, 1020 1 123 CY-158552-52100 Pump Assy,Feed 1

66 CY-24372-000150 Ring, Backup T2 P 15 1 124 CY-158552-52500 O-Ring(Feed P Inner 1

67 CY-158552-51600 Packing, Head 1 125 CY-129916-59020

Joint 12, Pipe 1

68 CY-158553-51630 Spring,Timer 1 127 CY-22190-120002 Seal Washer 12 2

70 CY-158553-51640 Element, Thermo 1 128 CY-23857-060000 Joint Bolt 6,Pipe 1

71 CY-158553-51660 O-Ring,P14 1 129 CY-119802-51250 Bracket, Pump 1

72 CY-158553-51680 Packing,Timer 1 130 CY-26106-080162 Bolt M 8X 16 Plated 1

94 CY-158601-51790 Plug 1 131 CY-26106-080202 Bolt M 8X 20 Plated 1

95 CY-22190-120002 Seal Washer 12 1

FIG. 12. FUEL INJECTION PUMP
